• Air conditioning
• AM/FM stereo w/cassette/CD changer control-inc: (4) speakers
• Black vinyl floor covering
• Cab back panel storage
• Cigar lighter/pwr outlet
• Day/night rearview mirror
• HD vinyl 40/20/40 split bench seat
• Instrument cluster-inc: 120 MPH primary speedometer, tachometer
• Passenger assist handle

• 136-amp alternator
• 17" x 7" argent painted steel wheels
• 3.55 axle ratio
• 600-amp maintenance-free battery
• 9.25" rear axle ring gear diameter
• Front stabilizer bar
• Full-size spare tire w/winch-type carrier
• HD front/rear shock absorbers
• P245/70R17 all-season SBR BSW tires
• Pwr 4-wheel disc brakes-inc: rear-wheel anti-lock
• Pwr rack & pinion steering
• Rear wheel drive

• Driver/passenger "Next Generation" airbags w/passenger on/off switch
• Dual note horn
• Rear-wheel anti-lock brakes
• Shoulder belt height adjusters

3.7L V6 "MAGNUM" ENGINE

• (STD)

• Rear Wheel Drive
• Tires - Front All-Season
• Tires - Rear All-Season
• Conventional Spare Tire
• Steel Wheels
• Power Steering
• 4-Wheel Disc Brakes
• Intermittent Wipers
• Variable Speed Intermittent Wipers
• Vinyl Seats
• Split Bench Seat
• A/C
• AM/FM Stereo
• Cassette
• Power Outlet
• Driver Air Bag
• Passenger Air Bag
• Passenger Air Bag On/Off Switch

• Mileage
• EPA Fuel Economy Est - City (MPG): 16
• EPA Fuel Economy Est - Hwy (MPG): 21
• Electrical
• Cold Cranking Amps @ 0° F (Primary): 600
• Maximum Alternator Capacity (amps): 136
• Maximum Alternator Watts: 1904
• Cooling System
• Total Cooling System Capacity (qts): 17
• Weight Information
• Gross Axle Wt Rating - Front (lbs): - TBD -
• Gross Axle Wt Rating - Rear (lbs): 3900
• Curb Weight - Front (lbs): 2484
• Curb Weight - Rear (lbs): 2032
• Gross Vehicle Weight Rating Cap (lbs): 6350
• Gross Combined Wt Rating (lbs): 8,500
• Gross Combined Wt Rating (lbs): 8,000
• Trailering
• Dead Weight Hitch - Max Trailer Wt. (lbs): 5000
• Dead Weight Hitch - Max Tongue Wt. (lbs): 500
• Wt Distributing Hitch - Max Trailer Wt. (lbs): - TBD -
• Wt Distributing Hitch - Max Tongue Wt. (lbs): - TBD -
• Suspension
• Suspension Type - Front: Independant SLA
• Suspension Type - Rear: Leaf spring
• Spring Capacity - Front (lbs): 3650
• Spring Capacity - Rear (lbs): 3800
• Axle Type - Rear: Semi-floating
• Axle Capacity - Front (lbs): 3650
• Axle Capacity - Rear (lbs): 3900
• Axle Ratio (:1) - Rear: 3.55
• Shock Absorber Diameter - Front (mm): - TBD -
• Shock Absorber Diameter - Rear (mm): - TBD -
• Stabilizer Bar Diameter - Front (in): - TBD -
• Brakes
• Brake Type: Pwr
• Brake ABS System: Rear Wheel
• Disc - Front (Yes or ): Yes
• Disc - Rear (Yes or ): Yes
• Front Brake Rotor Diam x Thickness (in): 13.2 x 1.1
• Rear Brake Rotor Diam x Thickness (in): 13.8 x .87
• Tires
• Front Tire Size: P245/70R17
• Rear Tire Size: P245/70R17
• Spare Tire Size: P245/70R17
• Front Tire Capacity (lbs): - TBD -
• Rear Tire Capacity (lbs): - TBD -
• Spare Tire Capacity (lbs): - TBD -
• Revolutions/Mile @ 45 mph - Front: - TBD -
• Revolutions/Mile @ 45 mph - Rear: - TBD -
• Revolutions/Mile @ 45 mph - Spare: - TBD -
• Wheels
• Front Wheel Size (in): 17 x 7.0
• Rear Wheel Size (in): 17 x 7.0
• Spare Wheel Size (in): 17 x 7.0
• Front Wheel Material: Steel
• Rear Wheel Material: Steel
• Spare Wheel Material: Steel
• Steering
• Steering Type: Pwr rack & pinion
• Steering Ratio (:1), On Center: 15.4
• Steering Ratio (:1), At Lock: - TBD -
• Turning Diameter - Curb to Curb (ft): 39.0
• Turning Diameter - Wall to Wall (ft): - TBD -
• Frame
• Frame Type: Ladder
• Fuel Tank
• Fuel Tank Capacity, Approx (gal): 26.0
• Fuel Tank Location: Inboard Frame Rails
• Exterior Dimensions
• Wheelbase (in): 120.5
• Length, Overall w/o rear bumper (in): - TBD -
• Width, Max w/o mirrors (in): 79.9
• Height, Overall (in): 74.4
• Overhang, Front (in): 39.4
• Overhang, Rear w/o bumper (in): 47.9
• Front Bumper to Back of Cab (in): 123.0
• Cab to Axle (in): 36.9
• Cab to End of Frame (in): 4.9
• Ground to Top of Load Floor (in): 34.0
• Ground to Top of Frame (in): - TBD -
• Frame Width, Rear (in): - TBD -
• Ground Clearance, Front (in): 8.3
• Ground Clearance, Rear (in): 8.1
• Cargo Area Dimensions
• Cargo Box Length @ Floor (in): 75
• Cargo Box Width @ Top, Rear (in): - TBD -
• Cargo Box Width @ Floor (in): 66.4
• Cargo Box Width @ Wheelhousings (in): 51.0
• Cargo Box (Area) Height (in): 20.1
• Tailgate Width (in): 63.4
• Cargo Volume (ft³): 57.7
• Interior Dimensions
• Passenger Capacity: 3
• Front Head Room (in): 40.9
• Front Leg Room (in): 41.0
• Front Shoulder Room (in): 67.0
• Front Hip Room (in): 65.1
• Summary
• Vehicle Name: Dodge Ram 1500
• Body Style: Reg Cab 6.25' Bed
• Body Code: 120.5" WB
